Discover the mobile home Q18 from PROTEC

Discover the mobile home Q18 from PROTEC




LAYOUT

As a standard vehicle we offer two layout choices: the Q18 CLASSIC and the Q18 VARIO. The plus options include a sleeping alcove with a double bed (200cm x140cm). In the standard fittings and features the roof mounting can be used as storage room.



LAYOUT

As a standard vehicle we offer two layout choices: the Q18 CLASSIC and the Q18 VARIO. The plus options include a sleeping alcove with a double bed (200cm x140cm). In the standard fittings and features the roof mounting can be used as storage room.

LAYOUT

As a standard vehicle we offer two layout choices: the Q18 CLASSIC and the Q18 VARIO. The plus options include a sleeping alcove with a double bed (200cm x140cm). In the standard fittings and features the roof mounting can be used as storage room.

  • Example

  • Example


  • Example

  • Example



FIXTURES AND FEATURES

We will build your mobile home according to your individual wishes and requirements. As well as our well-conceived and comprehensive standard fixtures you have the possibility of adding our special features to create your own dream mobile home. We only use materials of the best quality for all our components, ensuring that our Q18 satisfies the highest demands. Discover our large range of highlights and convince yourself.



FIXTURES AND FEATURES

We will build your mobile home according to your individual wishes and requirements. As well as our well-conceived and comprehensive standard fixtures you have the possibility of adding our special features to create your own dream mobile home. We only use materials of the best quality for all our components, ensuring that our Q18 satisfies the highest demands. Discover our large range of highlights and convince yourself.

FIXTURES AND FEATURES

We will build your mobile home according to your individual wishes and requirements. As well as our well-conceived and comprehensive standard fixtures you have the possibility of adding our special features to create your own dream mobile home. We only use materials of the best quality for all our components, ensuring that our Q18 satisfies the highest demands. Discover our large range of highlights and convince yourself.

Standard Vehicle

Technical Data
  • Standard Vehicle: IVECO Daily
  • Chassis Type: 70 C 18 L
  • Motor: 4 Cylinder
  • Cubic Capacity: 3.0 l
  • Output (at 3.000 - 3.500 min - 1): 180 hp
  • Torque Value (at 1.500 - 2.750 min-1): 430 Nm
  • Total Length (mm): 7.850
  • Total Width (mm) 2.330
  • Total Height without superstructure (mm) 3.250 / 3.350
    without alcoves / with alcoves (plus)
  • Wheelbase (mm): 4.350
  • Technically permissible overall mass (kilos): 7.200
  • Additional Load (kilos) depending on fittings: up to 1.400
  • Towing Capacity in kilos: up 3.500
  • Seats with three-point safety belts: 4/6
    Q18 CLASSIC / Q18 VARIO
Chassis Iveco Daily
  • Standard solid paintwork
  • Turbo diesel engine with rear-wheel drive and dual (twin) tyres
  • EURO 6 with particulate filter
  • Six-speed manual transition
  • Traction control system (ASR) and electronic stability program (ESP)
  • Electronically-controlled anti-blocking system (ABS)
  • Cruise Control
  • Electric window regulators for driver and passenger side
  • Generator 210 A
  • Fuel Tank 90 litre including filler neck in B-pillar
  • Heated external and electronically adjustable mirrors
  • Spare wheel with spare wheel mounting
  • Provision for trailer socket
  • Pre-installation of radio (blinded Double-DIN available)
  • Front axle load: 2.700 kilos
  • Fog lights with static cornering light
  • Central locking system with remote control
  • Driver and passenger airbags
  • Deluxe driver seat, 3-way adjustable with hydraulic suspension and heatable
  • Deluxe passenger seat, 3-way adjustable with hydraulic suspension and heatable
  • Commitment fee ex works Wessling including full standard fuel tank

Vehicle Structure
  • GFK roof extension with 2 storage spaces
  • Box body made of extremely stable GFK sandwich panels
    (With PU foam, wall thickness c. 44 mm, floor c. 53 mm, roof c. 54 mm)
  • Rear wall cladding and rear bumper, as well as side box flaps formed in solid GFK
  • Exterior paintwork with gelcoat protective coating similar to RAL 9001
  • Hydraulic supporting jack system with automatic leveling
  • Double glazed tinted smoke-grey plastic windows with blackout blinds and fly screens:
    2 roof windows and 5 side windows with the 1-room Q18 CLASSIC
    2 roof windows and 4 side windows with the 2-room Q18 VARIO
  • Entrance door with window and fly screen
  • External electrically extendable access step with safety circuit
  • Room height: 2.18 m (central body) and 2.06 m (Slide-Outs)

Basic Fittings and Features

Fittings included in basic price:
(Errors and technical changes subject to modification.)

General
  • ALDE 3020 gas-powered hot water central heating
  • Fresh water tank c. 290 litre, insulated and heatable
  • Waste water tank c. 260 litre, insulated and heatable
  • Fuel tank 90 litre built into the chassis
  • All walls and ceilings except the shower covered with cream-coloured microfibre
  • High pressure laminate surface flooring
  • Direct LED lighting in all rooms
  • 230 Volt sockets in all rooms
  • Storage shelfs in living area, sleeping areas and bathroom
  • Sleeping areas separated from living area by walls with doors
Living Area
  • Seating group, when used as living space with folding bench seat:
    5 seats, 2 of which are equipped with safety belts in the 1-room Q18 CLASSIC
    6 seats, 4 with safety belts in the 2-room Q18 VARIO
  • Seats and upholstery covered with microfibre/material
  • Lowerable and movable table
  • Upholstery adaptable to a bed surface
  • Storage box below the seating group
  • 1 wall cabinet, 195 cm length x 50 cm height x 30 cm depth
  • 1 cupboard , 206 cm height x 65 cm width x 60 cm depth with drawers and doors with the 2-room Q18 VARIO
  • 1 cupboard 190 cm height x 45 cm width x 60 cm depth with drawers and doors with the 2-room Q18 VARIO
Kitchen
  • Worktop 125 cm length x 58 cm width with sink and gas cooker, 3-burner gas hob
  • Additional pull-out cutting board Q18 VARIO
  • Drawers, pull-out and curved door below the worktop
  • 1 wall cabinet, 125 cm length x 50 cm width x 30 cm depth
  • 1 kitchen cupboard, 206 cm height x 70 cm width x 40 cm depth with the 1-room Q18 CLASSIC
    1 kitchen cupboard, 206 cm height x 45 cm width x 60 cm depth with the 2-room Q18 VARIO
  • 1 cupboard, 190 cm height x 55 cm width x 60 cm depth for a refrigerator with shelf, space for a flat screen TV up to 21.5”, alternatively oven
  • Refrigerator 160 l with separate freezer compartment, AES (automatic and manual energy selection system 12 Volt / 230 Volt / gas)
Shower/WC

Shower 1-room Q18 CLASSIC

  • 1 washbasin cabinet with worktop washbasin
  • 1 mirror cabinet H 69 cm x B 69 cm x T 15 cm
  • Storage shelfs
  • Shower tray 70 cm length x 70 cm width
  • Shower wall between shower and anteroom

WC 1-room Q18 CLASSIC

  • 1 wall cabinet L 60 cm x H 48 cm x 30cm
  • Cassette toilet
  • Small wash basin
  • Mirror

Shower/WC 2-room Q18 VARIO

  • Opening basin
  • 1 mirror cabinet, 60 cm length x 72 cm width x 15 cm depth
  • Storage shelfs
  • Cassette toilet
  • Shower tray, 72 cm length x 72 cm width
  • Shower wall between shower and anteroom
  • Shower curtain
Sleeping Area

All beds with slatted frames and covered cold-foam mattresses

1-room Q18 CLASSIC

  • Double bed, 210 cm length x 160 cm width
  • 1 wall cupboard, 160 cm length x 50 cm width x 30 cm depth
  • 1 wall cupboard unit, 160 cm width x 60 cm depth

2-room Q18 VARIO

  • Each with one, height-adjustable bed, 200 cm length, for increasing the storage space below
  • Each bed extendable from 70 cm to 130 cm
  • Each with a wall cupboard, c 200 cm length x 40 cm height x 30 cm depth
Electrics
  • 2 FI personal security automats
  • 1 living area battery 180 Ah (AGM)
  • 230 V automatic battery charger with electronic control, maximum loading current 35 A
  • Automatic charging of body battery and vehicle battery
  • Charge retention by external power source as well as during travel
  • Automatic connection and disconnection of body battery and vehicle battery
  • Power inverter from 12 V to 230 V, continuous output 1.800 W / top performance 3.200 W, with mains priority circuit
  • 230 V CEE power socket in utility room, with cable feed-through in the floor to the outside
  • Air compressor with tank and external connection
  • Multi-Panel-System to oversee the followings (and others):
    Fresh water tank (level in %)
    Waste water tank (level in %)
    Battery voltage level of vehicle and body battery
    External power source (supply status 12 V or 230 V)



Further additional fittings and features available on request.

Additional Fittings and Features

Additional Fittings and Features
(Errors and technical changes subject to modification.)

Chassis IVECO Daily
  • IVECO New Daily, Motor Turbo diesel EURO 6, including 8 speed gearbox converter for automatic transmission HI-MATIC, with 205 hp at 3.000 - 3.500 min-1, torque value 470 Nm at 1.500 - 3.000 min-1
  • Solid paint in special colours
  • Metallic paintwork
  • Laden mass 7.490 kg maximum permitted weight
    (Trailer weight up to maximum 3.500 kg)
  • Towing hitch with rigid ball head with towable weight up to 3.500kg* (only available with factory assembly)
  • Stainless steel wheel covers
  • 8 speed gearbox converter for automatic transmission HI-MATIC for 180 hp motor
  • Differential lock for rear axle
  • Pneumatic suspension for the rear axle, with the feature “Lifting and lowering”
    (Total stroke path air suspension maximum: rear axle c. 100 mm)
  • Pneumatic suspension for the front and rear axle, with the feature “Lifting and lowering”
    (Total stroke path air suspension maximum: front axle c. 30 mm, rear axle c. 110 mm)
  • Automatic air-conditioning for driver cab
  • Leather steering wheel IVECO with multifunctional keys
  • Driver- and passenger seat leather upholstery (same material as seating group)
  • Carpet in driver´s cab
  • Interior optional HI-MATIC blue
  • Central locking alarm system
  • Third vehicle key with remote control
  • Heatable windscreen - only in area of windscreen wipers
  • Mediacenter with navigation for camper, 7" touchscreen
    (Apple CarPlay, Bluetooth, CD / DVD and DAB+)
  • Digital radio DAB+ and Sat Nav with IVECO app including tablet mounting (upgraded)
    (Radio, Sat Nav and rear camera without display: personal tablet is obligatory)
  • Bluetooth radio Sat Nav + navigation map from IVECO Shop
  • Lane warning alert assistant

*Taking into consideration the total towing weight of 10,7 t (manual transmission) and 10,5 t (automatic transmission HI-MATIC)

Structure
  • Q18 CLASSIC plus/Q18 VARIO plus
    (Alcoves with double bed, c 200cm length x c 140cm width)
  • Seating group with high quality leather upholstery (choice by arrangement)
  • Additional indirect LED lighting in all rooms
  • Dimmable LED lightning (up to 4 single areas)
  • Seperation between driver’s cab and living area
  • Decorative interior blinds or curtains with deco hangings
  • Various versions of fridge and combinations fridge and oven
  • Corian kitchen worktop with sink (stainless steel bottom)
  • Corian washing stand with top glass-sink 1-room Q18 CLASSIC
  • Electric closing aid for entrance door
  • Telescope leaning-ladder (Aluminium)
  • Fiamma marquee 4 m x 2,50 m, manual
  • Omnistor marquee, 4 m x 2.75 m, manual
  • LED marquee lighting
  • Roof rack system Euro Carry Reling Future L 260 x ca. B 65 cm
  • Roof air conditioner 2.400 W with 1.700 W heating element (Total vehicle height: c. 3.400 mm)
  • Roof air conditioner 2.800 W with 3.300 W heating element (Total vehicle height: c. 3.400 mm)
  • Solar panel including accessories
  • Living room battery (Lithium ion 200 Ah)
  • Skylight in bedroom, Heki 3 plus instead of Mini-Heki, 1-room Q18 CLASSIC
  • Additional skylights in living area Q18 VARIO
  • 2 storage compartments with needle felt floor covering
    <em<(rear right, 187 cm length x 45 cm height x 50 cm depth
  • 2 lashing rails with 4 adjustable eyelets per garage
  • Rear bike carriers for 2 to 4 bikes
  • Extra WC cassette for cassette toilet
  • Connection for external shower, cold and warm water
  • Connection for external gas
  • Gas detector
  • Double rear view camera with shutter, no monitor (colour-double-camera)
  • Sat system, TV, TV mount, Internet
  • TV covering for TV size up to 32”
  • Radio CD / DVD in living area, Soundsystem with Power Woofer and Multispeakers
  • USB double socket in living area
  • LED reading light with USB port (e.g. sleeping area, alcove etc.)



Further additional fittings and features available on request.

Standard Vehicle

Technical Data
  • Standard Vehicle: IVECO Daily
  • Chassis Type: 70 C 18 L
  • Motor: 4 Cylinder
  • Cubic Capacity: 3.0 l
  • Output (at 3.000 - 3.500 min - 1): 180 hp
  • Torque Value (at 1.500 - 2.750 min-1): 430 Nm
  • Total Length (mm): 7.850
  • Total Width (mm) 2.330
  • Total Height without superstructure (mm) 3.250 / 3.350
    without alcoves / with alcoves (plus)
  • Wheelbase (mm): 4.350
  • Technically permissible overall mass (kilos): 7.200
  • Additional Load (kilos) depending on fittings: up to 1.400
  • Towing Capacity in kilos: up 3.500
  • Seats with three-point safety belts: 4/6
    Q18 CLASSIC / Q18 VARIO
Chassis Iveco Daily
  • Standard solid paintwork
  • Turbo diesel engine with rear-wheel drive and dual (twin) tyres
  • EURO 6 with particulate filter
  • Six-speed manual transition
  • Traction control system (ASR) and electronic stability program (ESP)
  • Electronically-controlled anti-blocking system (ABS)
  • Cruise Control
  • Electric window regulators for driver and passenger side
  • Generator 210 A
  • Fuel Tank 90 litre including filler neck in B-pillar
  • Heated external and electronically adjustable mirrors
  • Spare wheel with spare wheel mounting
  • Provision for trailer socket
  • Pre-installation of radio (blinded Double-DIN available)
  • Front axle load: 2.700 kilos
  • Fog lights with static cornering light
  • Central locking system with remote control
  • Driver and passenger airbags
  • Deluxe driver seat, 3-way adjustable with hydraulic suspension and heatable
  • Deluxe passenger seat, 3-way adjustable with hydraulic suspension and heatable
  • Commitment fee ex works Wessling including full standard fuel tank

Vehicle Structure
  • GFK roof extension with 2 storage spaces
  • Box body made of extremely stable GFK sandwich panels
    (With PU foam, wall thickness c. 44 mm, floor c. 53 mm, roof c. 54 mm)
  • Rear wall cladding and rear bumper, as well as side box flaps formed in solid GFK
  • Exterior paintwork with gelcoat protective coating similar to RAL 9001
  • Hydraulic supporting jack system with automatic leveling
  • Double glazed tinted smoke-grey plastic windows with blackout blinds and fly screens:
    2 roof windows and 5 side windows with the 1-room Q18 CLASSIC
    2 roof windows and 4 side windows with the 2-room Q18 VARIO
  • Entrance door with window and fly screen
  • External electrically extendable access step with safety circuit
  • Room height: 2.18 m (central body) and 2.06 m (Slide-Outs)

Basic Fittings and Features

Fittings included in basic price:
(Errors and technical changes subject to modification.)

General
  • ALDE 3020 gas-powered hot water central heating
  • Fresh water tank c. 290 litre, insulated and heatable
  • Waste water tank c. 260 litre, insulated and heatable
  • Fuel tank 90 litre built into the chassis
  • All walls and ceilings except the shower covered with cream-coloured microfibre
  • High pressure laminate surface flooring
  • Direct LED lighting in all rooms
  • 230 Volt sockets in all rooms
  • Storage shelfs in living area, sleeping areas and bathroom
  • Sleeping areas separated from living area by walls with doors
Living Area
  • Seating group, when used as living space with folding bench seat:
    5 seats, 2 of which are equipped with safety belts in the 1-room Q18 CLASSIC
    6 seats, 4 with safety belts in the 2-room Q18 VARIO
  • Seats and upholstery covered with microfibre/material
  • Lowerable and movable table
  • Upholstery adaptable to a bed surface
  • Storage box below the seating group
  • 1 wall cabinet, 195 cm length x 50 cm height x 30 cm depth
  • 1 cupboard , 206 cm height x 65 cm width x 60 cm depth with drawers and doors with the 2-room Q18 VARIO
  • 1 cupboard 190 cm height x 45 cm width x 60 cm depth with drawers and doors with the 2-room Q18 VARIO
Kitchen
  • Worktop 125 cm length x 58 cm width with sink and gas cooker, 3-burner gas hob
  • Additional pull-out cutting board Q18 VARIO
  • Drawers, pull-out and curved door below the worktop
  • 1 wall cabinet, 125 cm length x 50 cm width x 30 cm depth
  • 1 kitchen cupboard, 206 cm height x 70 cm width x 40 cm depth with the 1-room Q18 CLASSIC
    1 kitchen cupboard, 206 cm height x 45 cm width x 60 cm depth with the 2-room Q18 VARIO
  • 1 cupboard, 190 cm height x 55 cm width x 60 cm depth for a refrigerator with shelf, space for a flat screen TV up to 21.5”, alternatively oven
  • Refrigerator 160 l with separate freezer compartment, AES (automatic and manual energy selection system 12 Volt / 230 Volt / gas)
Shower/WC

Shower 1-room Q18 CLASSIC

  • 1 washbasin cabinet with worktop washbasin
  • 1 mirror cabinet H 69 cm x B 69 cm x T 15 cm
  • Storage shelfs
  • Shower tray 70 cm length x 70 cm width
  • Shower wall between shower and anteroom

WC 1-room Q18 CLASSIC

  • 1 wall cabinet L 60 cm x H 48 cm x 30cm
  • Cassette toilet
  • Small wash basin
  • Mirror

Shower/WC 2-room Q18 VARIO

  • Opening basin
  • 1 mirror cabinet, 60 cm length x 72 cm width x 15 cm depth
  • Storage shelfs
  • Cassette toilet
  • Shower tray, 72 cm length x 72 cm width
  • Shower wall between shower and anteroom
  • Shower curtain
Sleeping Area

All beds with slatted frames and covered cold-foam mattresses

1-room Q18 CLASSIC

  • Double bed, 210 cm length x 160 cm width
  • 1 wall cupboard, 160 cm length x 50 cm width x 30 cm depth
  • 1 wall cupboard unit, 160 cm width x 60 cm depth

2-room Q18 VARIO

  • Each with one, height-adjustable bed, 200 cm length, for increasing the storage space below
  • Each bed extendable from 70 cm to 130 cm
  • Each with a wall cupboard, c 200 cm length x 40 cm height x 30 cm depth
Electrics
  • 2 FI personal security automats
  • 1 living area battery 180 Ah (AGM)
  • 230 V automatic battery charger with electronic control, maximum loading current 35 A
  • Automatic charging of body battery and vehicle battery
  • Charge retention by external power source as well as during travel
  • Automatic connection and disconnection of body battery and vehicle battery
  • Power inverter from 12 V to 230 V, continuous output 1.800 W / top performance 3.200 W, with mains priority circuit
  • 230 V CEE power socket in utility room, with cable feed-through in the floor to the outside
  • Air compressor with tank and external connection
  • Multi-Panel-System to oversee the followings (and others):
    Fresh water tank (level in %)
    Waste water tank (level in %)
    Battery voltage level of vehicle and body battery
    External power source (supply status 12 V or 230 V)



Further additional fittings and features available on request.

Additional Fittings and Features

Additional Fittings and Features
(Errors and technical changes subject to modification.)

Chassis IVECO Daily
  • IVECO New Daily, Motor Turbo diesel EURO 6, including 8 speed gearbox converter for automatic transmission HI-MATIC, with 205 hp at 3.000 - 3.500 min-1, torque value 470 Nm at 1.500 - 3.000 min-1
  • Solid paint in special colours
  • Metallic paintwork
  • Laden mass 7.490 kg maximum permitted weight
    (Trailer weight up to maximum 3.500 kg)
  • Towing hitch with rigid ball head with towable weight up to 3.500kg* (only available with factory assembly)
  • Stainless steel wheel covers
  • 8 speed gearbox converter for automatic transmission HI-MATIC for 180 hp motor
  • Differential lock for rear axle
  • Pneumatic suspension for the rear axle, with the feature “Lifting and lowering”
    (Total stroke path air suspension maximum: rear axle c. 100 mm)
  • Pneumatic suspension for the front and rear axle, with the feature “Lifting and lowering”
    (Total stroke path air suspension maximum: front axle c. 30 mm, rear axle c. 110 mm)
  • Automatic air-conditioning for driver cab
  • Leather steering wheel IVECO with multifunctional keys
  • Driver- and passenger seat leather upholstery (same material as seating group)
  • Carpet in driver´s cab
  • Interior optional HI-MATIC blue
  • Central locking alarm system
  • Third vehicle key with remote control
  • Heatable windscreen - only in area of windscreen wipers
  • Mediacenter with navigation for camper, 7" touchscreen
    (Apple CarPlay, Bluetooth, CD / DVD and DAB+)
  • Digital radio DAB+ and Sat Nav with IVECO app including tablet mounting (upgraded)
    (Radio, Sat Nav and rear camera without display: personal tablet is obligatory)
  • Bluetooth radio Sat Nav + navigation map from IVECO Shop
  • Lane warning alert assistant

*Taking into consideration the total towing weight of 10,7 t (manual transmission) and 10,5 t (automatic transmission HI-MATIC)

Structure
  • Q18 CLASSIC plus/Q18 VARIO plus
    (Alcoves with double bed, c 200cm length x c 140cm width)
  • Seating group with high quality leather upholstery (choice by arrangement)
  • Additional indirect LED lighting in all rooms
  • Dimmable LED lightning (up to 4 single areas)
  • Seperation between driver’s cab and living area
  • Decorative interior blinds or curtains with deco hangings
  • Various versions of fridge and combinations fridge and oven
  • Corian kitchen worktop with sink (stainless steel bottom)
  • Corian washing stand with top glass-sink 1-room Q18 CLASSIC
  • Electric closing aid for entrance door
  • Telescope leaning-ladder (Aluminium)
  • Fiamma marquee 4 m x 2,50 m, manual
  • Omnistor marquee, 4 m x 2.75 m, manual
  • LED marquee lighting
  • Roof rack system Euro Carry Reling Future L 260 x ca. B 65 cm
  • Roof air conditioner 2.400 W with 1.700 W heating element (Total vehicle height: c. 3.400 mm)
  • Roof air conditioner 2.800 W with 3.300 W heating element (Total vehicle height: c. 3.400 mm)
  • Solar panel including accessories
  • Living room battery (Lithium ion 200 Ah)
  • Skylight in bedroom, Heki 3 plus instead of Mini-Heki, 1-room Q18 CLASSIC
  • Additional skylights in living area Q18 VARIO
  • 2 storage compartments with needle felt floor covering
    <em<(rear right, 187 cm length x 45 cm height x 50 cm depth
  • 2 lashing rails with 4 adjustable eyelets per garage
  • Rear bike carriers for 2 to 4 bikes
  • Extra WC cassette for cassette toilet
  • Connection for external shower, cold and warm water
  • Connection for external gas
  • Gas detector
  • Double rear view camera with shutter, no monitor (colour-double-camera)
  • Sat system, TV, TV mount, Internet
  • TV covering for TV size up to 32”
  • Radio CD / DVD in living area, Soundsystem with Power Woofer and Multispeakers
  • USB double socket in living area
  • LED reading light with USB port (e.g. sleeping area, alcove etc.)



Further additional fittings and features available on request.



Dimensions and weights are approximate measurements and can vary. Errors and technical changes are subject to modification. Only vendor parts of the highest quality are used. Manufacture of our vehicles is carried out in our main site in Wessling near Munich. Status as of April 2018.
